RAMFAN EFC50X 16" Fire Rescue Smoke Ejector
RAMFAN EFC50X 16" Fire Rescue Smoke Ejector
SKU:EA7000X
Regular price
$ 2,420.60
Regular price
$ 2,548.00
Sale price
$ 2,420.60
Out of stock
Request bulk pricing
Quantity
Couldn't load pickup availability
Product Description
These EFCx Series Smoke Ejectors are built with a high-impact, heat-resistant Lexan® housing and an UL/IECEx/ATEX-certified explosion-proof motor for use in areas where potentially explosive gasses are unlikely to be present; establishing and ensuring a safer work environment.
The Polymer TurboForce™ impeller is engineered to enhance performance as well as maximizing the airflow; allowing the smoke ejection time to reduce dramatically and bringing fresh air into the confined space more effectively.
Specifications:
| Model | EFC50x |
| Part | EA7000X |
| Weight | 49 lbs / 22 kg |
| Dimensions (h/w/d) | 19 x 18 x12 in 48 x 46 x 31 cm |
|
Amps: Start Run |
115V: 21A 115V: 6A |
| Motor | 0.5 Hp / 0.37 kW |
| Noise | 90.2 dB @ 3′ (1 m) |
| Electric | 115/230V, 1ø, 50/60Hz |
| Approvals | CSA, UL, CE |
| Airflow | |
| Free Air | 3,200 cfm (5,440 m3/hr) |
|
Through Duct 15’/4.6 m w/ one 90° turn: |
1,935 cfm (3,289 m³/hr) |
