Nachi Bearings 8049-30600 Double Row Angular Contact Bearing

5306 Nachi Double Row Angular Ball Bearing 30mm x 72mm x 30.2mm Made in Japan 5306 Nachi Double Row Angular Ball Bearing, Made in Japan, inner diameter is 30mm, outer diameter is 72mm and width is 30.2mm. * Item: 5306 Nachi Ball Bearing * Type: Nachi Double Row Angular Ball Bearing * Closures: Open * Dimensions: 30mm x 72mm x 30.2mm/Metric * ID (inner diameter)/Bore: 30mm * OD (outer diameter): 72mm * Width/Height/thickness:30.2mm * Size: 30 x 72 x 30.2 mm * Quantity: One Bearing * Dynamic load rating Cr: 41,500 N * Static load rating Cor: 29,000 N * Limiting Speed: * Grease Lubrication: 7,000 RPM * Oil Lubrication: 9,500 RPM * Made in Japan Nachi Double Row Angular Contact Bearing The construction of this type ball bearing is similar to the adjacent, BACK-TO-BACK mounting of two Single-row Angular Contact ball bearings. Because fewer balls can be inserted per row compared to Single-row Angular Contact ball bearings, a Double-row Angular Contact ball bearing will have less load capacity than an equivalent size/series BACK-TO-BACK set of two Single-row Angular Contact ball bearings. This bearing type can sustain radial, moment and bi-directional axial loads.

• Item: 5306 Nachi Ball Bearing
• Type: Nachi Double Row Angular Ball Bearing
• Closures: Open
• Dimensions: 30mm x 72mm x 30.2mm/Metric
• ID (inner diameter)/Bore: 30mm
