D85EC Thermal Mass Air Dryer

Higher Efficiency, Lower Cost

The Ingersoll Rand D-EC cycling refrigerated dryer design helps you achieve optimal performance at a lower cost compared to a non-cycling design. To reduce energy consumption, the dryer refrigeration system automatically deactivates during periods of low load and features a patented heat exchanger and thermal mass circuit.
Thermal mass dryers use a simple but efficient refrigeration system that cools a liquid solution that then cools the compressed air, removing harmful moisture from your air stream. This type of refrigeration methods allows the refrigeration compressor to shut down during periods of low flow, with considerable reduction in power costs over other designs. This smart design also has the lowest operating kW, the lowest pressure drop and cycles off in periods of low demand.

Variable dewpoint settings
Heavy duty construction meant to last
Lowest running costs of any refrigeration dryer
Easily serviced
Easy-to-read information panels

Technical Details

50 SCFM (air flow)
200 Max PSI
115-1-60 voltage
Weight: 105 pounds
Dimensions: 16L x 20W x 27H
