CAT 143-0539 Starting Motor Gp-Electric

12 Volt Heavy Duty Electric Starting Motor

Built to work hard and deliver reliable performance even in tough, dirty, bitter-cold conditions, Cat® Starters are designed to handle the high current needed when cranking cold engines. Every time. The Brush-Type Design uses one-piece brushes for less maintenance, and constant-pressure springs for even brush wear. Cat Starters are engineered to be part of a balanced electrical system, working in unison with the rest of your Cat engine components. Each unit is rigorously tested, so you know you’re getting genuine Cat reliability. Off-the-shelf availability minimizes your down time, and all Cat diesel engine parts come with a 12-month warranty.

• Designed to crank to -32 °C (-25 °F).

• Unmatched starting capacity compared to even the best competitors’ products.

• Highest sealing and anti-corrosion specs in the industry: seamless, one-piece solenoid casing that protects against corrosion, vibration and extreme weather.

• You’re buying less downtime and lower repair bills, helping you achieve the lowest owning and operating costs over your engine’s lifecycle.

SPECIFICATIONS:

Voltage (volts): 12
Mount Circle (mm): 127.0
Material: Alloy Aluminum
Electric Starting and/or Prelube: Electric Starting
Pinion Pitch: 8/10
Mount Size (Nose Cone): SAE No. 1 Nose housing, 50 mt.
Pinion Teeth: 10/11
Marine Approved: No
Current (Amps): 200

Compatible Models

SKID STEER LOADER
252B 236B

BACKHOE LOADER
424D 436C 442D 420D 430D 432D 438C 416C 428D 426C 416D 438D 428C 420F 430F 426 F2

COMPACT WHEEL LOADER
908

TELEHANDLER
TH62 TH63 TH82 TH103 TH83
