164-5039 O-ring

Not Compatible With: Acetone; Aromatic hydrocarbons; EP oil; Fuel oil; Gasoline; Ketones; Low aniline point oils; Petroleum oils; Steam & hot water
Temp.: -46° - 150° C

-50° - 300° F
Seal Inside Dia (mm): 574.00
Compatible With: Air; Diacetone alcohol; Ethylene glycol; Extreme high/low temperatures; High aniline point oil; Iso-butyl alcohol; Ozone & UV light; Polyglycol
Application(s): Electrical system seals; High temperature air seals; High temperature static grease seals
Material: Silicone (70), VMQ - Silicone
Cross Section Diameter (mm): 5.34 mm, 5.3
Inside Diameter (mm): 574
Cross Section Diameter (in): 0.21
Length (MM): 228.6
Material Description: Silicone performs well in a wide range of temperatures -- from extremely low to moderately high -- and is excellent in Air applications. It is also compatible with Engine Oil. It has limited strength and abrasion/cut resistance, so it is better in low pressure applications. Silicone should not be used with Diesel Fuel, Coolant/Urea, Hydraulic Oil, Automatic Transmission Fluid or Biodiesel.
Width (MM): 177.8
Coating: None
Height(mm): 2.5
Weight (kg): 0.05
